Medium Diameter Structural Carbon Fiber Tubes
3.0", 3.9", and 6.0"

Introducing our medium diameter carbon fiber tubes, originally developed for small research aircraft, now available for all your applications.


Made with aerospace quality carbon fiber cloth and convolute wrapped using a tight 3k 8 harness satin weave common in aerospace applications, our tubes have a fiber/resin ratio of 60/40% by weight. With 0/90 degree fiber orientation, they are cured under pressure and at high temperatures, ensuring strength and durability. After curing, the tubes are fine sanded and almost ready for painting. Primers and prep required. Upgrade to the strength of aerospace technology with our carbon fiber tubes.
The shipping costs listed below are for the contiguous 48 states via Ground UPS.
Please inquire for shipping to AK, HI and all international destinations sales@carbonscopetubes.com .
Shipping to Canada via USPS is generally just a few dollars more than shipping within the states.
Shipping costs to Europe typically run high depending on the tube ordered and the destination country.
International destinations vary widely and some have strict package size limits.

Shipping for multiple items will always be combined manually for the best rate. Your card may be charged a lesser amount or your PayPal account will receive a refund to reflect the lower shipping rate.
Structural carbon fiber tubes
Couplers tube for mating airframe sections

Contact us for thicker walls and tube cutting.



sales@carbonscopetubes.com
3.0" ID Ultra-Lite Carbon Tube
0.034" wall, 60" long, smooth sanded.

CFAF-3.0-UL-60
$269.95
3.0" ID Premium Carbon Tube
0.054" wall, 60" long, smooth sanded.

CFAF-3.0-PRM-60
$299.95
3.0" ID Extreme Carbon Tube
0.074" wall, 60" long, smooth sanded.

CFAF-3.0-EXT-60
$329.95
3.0" OD Carbon Coupler Tube    (CFCT-3.0-PRM-7.75)
0.054" wall, 7.75" long, use to couple two sections of 3.0" ID tubes listed above.
$49.95

3.9" ID Ultra-Lite Carbon Tube
0.034" wall, 60" long, smooth sanded.

CFAF-3.9-UL-60
$299.95
3.9" ID Premium Carbon Tube
0.054" wall, 60" long, smooth sanded.

CFAF-3.9-PRM-60
$339.95
3.9" ID Extreme Carbon Tube
0.074" wall, 60" long, smooth sanded.

CFAF-3.9-EXT-60
$389.95
3.9" OD Carbon Coupler Tube    (CFCT-3.9-PRM-7.75)
0.054" wall, 7.75" long, use to couple two sections of 3.9" ID tubes listed above.
$69.95

6.0" ID Ultra-Lite Carbon Tube
0.034" wall, 60" long, smooth sanded.

CFAF-6.0-UL-60
$469.95
6.0" ID Premium Carbon Tube
0.054" wall, 60" long, smooth sanded.

CFAF-6.0-PRM-60
$529.95
6.0" ID Extreme Carbon Tube
0.074" wall, 60" long, smooth sanded.

CFAF-6.0-EXT-60
$589.95
6.0" OD Carbon Coupler Tube    (CFCT-6.0-PRM-7.75)
0.054" wall, 14.75" long, use to couple two sections of 6.0" ID tubes listed above.
$99.95
